Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Power Relay B | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Electromagnetic Coil Design | Non Latching | |
| Electromagnet Amp Draw | 94 mA | |
| Inductor Operating Volts | 24VDC | |
| Switch Contact Layout | SPDT (1 Form C) | |
| Pin Ampere Capacity | 50 A | |
| Switch Rated Volts | 24VDC - Nom | |
| Minimum Activation Volts | 16 VDC | |
| Release Voltage Level | 3 VDC | |
| Activation Response Time | 10 ms | |
| Reset Response Duration | 10 ms | |
| Key Product Highlights | Diode | |
| Attachment Mounting Style | Socketable | |
| Lead Termination Type | Plug In, Quick Connect - 0.250" (6.3mm) | |
| Ambient Temp Range | -40°C ~ 125°C |
Description
Supports coil current measured at 94 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 24VDC for reliable functionality. Utilizes a contact configuration categorized as SPDT (1 Form C). Supports a contact current rating of 50 A. Equipped with features categorized as Diode. Mounting configuration Socketable for structural stability. Needs a voltage of 16 VDC for effective activation. Requires a release voltage of 3 VDC for reliable functioning. Time duration 10 ms for the response upon activation. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Duration required 10 ms for reset and reaction. Classification series for the product or component Power Relay B. The switch's voltage specification 24VDC - Nom as per electrical regulations. Type of termination Plug In, Quick Connect - 0.250" (6.3mm) for connector or device.
