Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | G8V-RH | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Electromagnetic Coil Design | Non Latching | |
| Electromagnet Amp Draw | - | |
| Inductor Operating Volts | 12VDC | |
| Switch Contact Layout | SPST-NO (1 Form A) | |
| Pin Ampere Capacity | 35 A | |
| Switch Rated Volts | 16VDC - Max | |
| Minimum Activation Volts | 8 VDC | |
| Release Voltage Level | 1 VDC | |
| Activation Response Time | 20 ms | |
| Reset Response Duration | 20 ms | |
| Key Product Highlights | - | |
| Attachment Mounting Style | Socketable | |
| Lead Termination Type | Plug In | |
| Ambient Temp Range | -40°C ~ 125°C |
Description
Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as SPST-NO (1 Form A). Supports a contact current rating of 35 A. Mounting configuration Socketable for structural stability. Needs a voltage of 8 VDC for effective activation. Requires a release voltage of 1 VDC for reliable functioning. Time duration 20 ms for the response upon activation. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. Duration required 20 ms for reset and reaction. Classification series for the product or component G8V-RH. The switch's voltage specification 16VDC - Max as per electrical regulations. Type of termination Plug In for connector or device.
