Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ET1 | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| Electromagnetic Coil Design | Non Latching | |
| Electromagnet Amp Draw | 53.3 mA | |
| Inductor Operating Volts | 12VDC | |
| Switch Contact Layout | SPDT (1 Form C) | |
| Pin Ampere Capacity | 25 A | |
| Switch Rated Volts | 16VDC - Max | |
| Minimum Activation Volts | 6.5 VDC | |
| Release Voltage Level | 0.9 VDC | |
| Activation Response Time | 2.5 ms | |
| Reset Response Duration | 3 ms | |
| Key Product Highlights | Sealed - Fully | |
| Attachment Mounting Style | Through Hole | |
| Lead Termination Type | PC Pin | |
| Ambient Temp Range | -40°C ~ 85°C |
Description
Supports coil current measured at 53.3 mA. Designed with a coil type classified as Non Latching for optimal electrical efficiency. Operates with a coil voltage of 12VDC for reliable functionality. Utilizes a contact configuration categorized as SPDT (1 Form C). Supports a contact current rating of 25 A. Equipped with features categorized as Sealed - Fully. Mounting configuration Through Hole for structural stability. Needs a voltage of 6.5 VDC for effective activation. Requires a release voltage of 0.9 VDC for reliable functioning. Time duration 2.5 ms for the response upon activation. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Duration required 3 ms for reset and reaction. Classification series for the product or component ET1. The switch's voltage specification 16VDC - Max as per electrical regulations. Type of termination PC Pin for connector or device.
