Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 250000 | ₹ 2.22000 | ₹ 5,55,000.00 |
| 100000 | ₹ 2.44000 | ₹ 2,44,000.00 |
| 70000 | ₹ 2.55000 | ₹ 1,78,500.00 |
| 50000 | ₹ 2.65000 | ₹ 1,32,500.00 |
| 30000 | ₹ 2.83000 | ₹ 84,900.00 |
| 20000 | ₹ 2.99000 | ₹ 59,800.00 |
| 10000 | ₹ 3.30000 | ₹ 33,000.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Nominal Zener Voltage | 10 V | |
| Accuracy Tolerance Percentage | ±5% | |
| Maximum Power Handling | 500 mW | |
| Maximum Zener Impedance | 15 Ohms | |
| Reverse Leak at Voltage | 100 nA @ 7.5 V | |
| Max Forward Voltage Drop | 1.5 V @ 10 mA | |
| Ambient Temp Range | -55°C ~ 150°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1206 (3216 Metric) | |
| Vendor Package Type | 1206 |
Description
Shows reverse leakage current noted at 100 nA @ 7.5 V at Vr. Maximum Zzt impedance of 15 Ohms ensures circuit reliability. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 150°C (TJ) for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 1206 (3216 Metric) that offers mechanical and thermal protection. Type of package 1206 that preserves the integrity of the device. Maximum power capability 500 mW for safeguarding the device. Product status Active concerning availability and lifecycle. Supplier package type 1206 for component selection. Precision tolerance level ±5% in manufacturing processes. Maximum forward voltage drop Vf at If 1.5 V @ 10 mA for diodes. Typical Zener voltage Vz 10 V for voltage stabilization.
