Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tape & Box (TB) | |
| Availability Status | Obsolete | |
| Nominal Zener Voltage | 5.6 V | |
| Accuracy Tolerance Percentage | ±6% | |
| Maximum Power Handling | 370 mW | |
| Maximum Zener Impedance | 40 Ohms | |
| Reverse Leak at Voltage | 1 µA @ 2 V | |
| Max Forward Voltage Drop | 900 mV @ 10 mA | |
| Ambient Temp Range | - | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | DO-204AG, DO-34, Axial | |
| Vendor Package Type | DO34-A2 |
Description
Shows reverse leakage current noted at 1 µA @ 2 V at Vr. Maximum Zzt impedance of 40 Ohms ensures circuit reliability. Mounting configuration Through Hole for structural stability. Type of housing Tape & Box (TB) for safeguarding or transporting components. Style of the enclosure/case DO-204AG, DO-34, Axial that offers mechanical and thermal protection. Type of package DO34-A2 that preserves the integrity of the device. Maximum power capability 370 mW for safeguarding the device. Product status Obsolete concerning availability and lifecycle. Supplier package type DO34-A2 for component selection. Precision tolerance level ±6% in manufacturing processes. Maximum forward voltage drop Vf at If 900 mV @ 10 mA for diodes. Typical Zener voltage Vz 5.6 V for voltage stabilization.
