Stock:
Distributor: 160
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 100000 | ₹ 5.83000 | ₹ 5,83,000.00 |
| 10000 | ₹ 6.95000 | ₹ 69,500.00 |
| 1000 | ₹ 7.80000 | ₹ 7,800.00 |
| 500 | ₹ 8.46000 | ₹ 4,230.00 |
| 100 | ₹ 9.40000 | ₹ 940.00 |
Stock:
Distributor: 111
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 100000 | ₹ 7.29000 | ₹ 7,29,000.00 |
| 10000 | ₹ 8.69000 | ₹ 86,900.00 |
| 3425 | ₹ 9.75000 | ₹ 33,393.75 |
Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 2273 | ₹ 11.57000 | ₹ 26,298.61 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Nominal Zener Voltage | 16 V | |
| Accuracy Tolerance Percentage | ±6% | |
| Maximum Power Handling | 200 mW | |
| Maximum Zener Impedance | 40 Ohms | |
| Reverse Leak at Voltage | 50 nA @ 11.2 V | |
| Max Forward Voltage Drop | - | |
| Ambient Temp Range | -55°C ~ 150°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | SC-79, SOD-523F | |
| Vendor Package Type | SOD-523F |
Description
Shows reverse leakage current noted at 50 nA @ 11.2 V at Vr. Maximum Zzt impedance of 40 Ohms ensures circuit reliability. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 150°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case SC-79, SOD-523F that offers mechanical and thermal protection. Type of package SOD-523F that preserves the integrity of the device. Maximum power capability 200 mW for safeguarding the device. Product status Active concerning availability and lifecycle. Supplier package type SOD-523F for component selection. Precision tolerance level ±6% in manufacturing processes. Typical Zener voltage Vz 16 V for voltage stabilization.
