Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| AC Switch Triac Style | Standard | |
| Off-State Voltage Rating | 600 V | |
| Max RMS On-State Current | 12 A | |
| Max Gate Trigger Volts | 1.5 V | |
| Non-Repetitive Surge 50/60Hz | 120A @ 50Hz | |
| Max Gate Trigger Amps | 50 mA | |
| Maximum Holding Current | 60 mA | |
| Setup Arrangement | Single | |
| Ambient Temp Range | -40°C ~ 125°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | TO-220-3 | |
| Vendor Package Type | TO-220 |
Description
Configured in a manner identified as Single. Features a maximum gate trigger current (Igt) rated at 50 mA. Indicates the maximum holding current recorded at 60 mA. Is designed to manage surge current Itsm rated at 120A @ 50Hz for 50/60Hz. Supports RMS on-state current rated at 12 A. Mounting configuration Through Hole for structural stability. Temperature range -40°C ~ 125°C (TJ) for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case TO-220-3 that offers mechanical and thermal protection. Type of package TO-220 that preserves the integrity of the device. Product status Active concerning availability and lifecycle. Supplier package type TO-220 for component selection. Style of triac Standard used for alternating current switching. Maximum gate trigger voltage 1.5 V for SCR devices. The voltage 600 V when the device is not active for switches or semiconductors.
