Stock:
Distributor: 11
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 6 | ₹ 7,556.10000 | ₹ 45,336.60 |
| 3 | ₹ 8,118.58000 | ₹ 24,355.74 |
| 1 | ₹ 9,023.71000 | ₹ 9,023.71 |
Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 30 | ₹ 8,745.89000 | ₹ 2,62,376.70 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Internal Structure Design | Single | |
| Thyristor Diode Count | 1 SCR | |
| Off-State Voltage Rating | 1.6 kV | |
| Max Average On-State Current | 750 A | |
| Max RMS On-State Current | 1180 A | |
| Max Gate Trigger Volts | 3 V | |
| Max Gate Trigger Amps | 150 mA | |
| Non-Repetitive Surge 50/60Hz | 9600A, 10500A | |
| Maximum Holding Current | - | |
| Ambient Temp Range | -40°C ~ 125°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | TO-200 Variation |
Description
Features a maximum gate trigger current (Igt) rated at 150 mA. Is designed to manage surge current Itsm rated at 9600A, 10500A for 50/60Hz. Offers a maximum average on-state current It(AV) of 750 A. Supports RMS on-state current rated at 1180 A. Mounting configuration Chassis Mount for structural stability. Overall count of SCRs/diodes 1 SCR for circuit safeguarding. Temperature range -40°C ~ 125°C (TJ) for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case TO-200 Variation that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Configuration Single for components or materials. Maximum gate trigger voltage 3 V for SCR devices. The voltage 1.6 kV when the device is not active for switches or semiconductors.
