Stock:
Distributor: 142
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 259.88000 | ₹ 259.88 |
| 10 | ₹ 234.96000 | ₹ 2,349.60 |
| 25 | ₹ 221.61000 | ₹ 5,540.25 |
| 100 | ₹ 192.24000 | ₹ 19,224.00 |
| 250 | ₹ 192.24000 | ₹ 48,060.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Off-State Voltage Rating | 1.2 kV | |
| Max Gate Trigger Volts | 1.5 V | |
| Max Gate Trigger Amps | 50 mA | |
| Max On-State Voltage Drop | 1.75 V | |
| Max Average On-State Current | 25 A | |
| Max RMS On-State Current | 40 A | |
| Maximum Holding Current | 100 mA | |
| Maximum Off-State Current | 10 µA | |
| Non-Repetitive Surge 50/60Hz | 435A, 400A | |
| Silicon Controlled Rectifier Style | Standard Recovery | |
| Ambient Temp Range | -40°C ~ 125°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | - | |
| Vendor Package Type | - |
Description
Features a maximum gate trigger current (Igt) rated at 50 mA. Indicates the maximum holding current recorded at 100 mA. Is designed to manage surge current Itsm rated at 435A, 400A for 50/60Hz. Features a maximum off-state current of 10 µA. Offers a maximum average on-state current It(AV) of 25 A. Supports RMS on-state current rated at 40 A. Mounting configuration Through Hole for structural stability. Temperature range -40°C ~ 125°C (TJ) for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. Product status Obsolete concerning availability and lifecycle. The Standard Recovery SCR type for thyristor properties. Maximum gate trigger voltage 1.5 V for SCR devices. The voltage 1.2 kV when the device is not active for switches or semiconductors. The highest voltage drop Vtm 1.75 V in the active state for semiconductors.
