Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 30 | ₹ 17,166.23000 | ₹ 5,14,986.90 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Off-State Voltage Rating | 1.2 kV | |
| Max Gate Trigger Volts | 3 V | |
| Max Gate Trigger Amps | 150 mA | |
| Max On-State Voltage Drop | 1.55 V | |
| Max Average On-State Current | 175 A | |
| Max RMS On-State Current | 275 A | |
| Maximum Holding Current | - | |
| Maximum Off-State Current | 25 mA | |
| Non-Repetitive Surge 50/60Hz | 5000A, 5500A | |
| Silicon Controlled Rectifier Style | Standard Recovery | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis, Stud Mount | |
| Component Housing Style | TO-209AB, TO-93-4, Stud | |
| Vendor Package Type | - |
Description
Features a maximum gate trigger current (Igt) rated at 150 mA. Is designed to manage surge current Itsm rated at 5000A, 5500A for 50/60Hz. Features a maximum off-state current of 25 mA. Offers a maximum average on-state current It(AV) of 175 A. Supports RMS on-state current rated at 275 A. Mounting configuration Chassis, Stud Mount for structural stability. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case TO-209AB, TO-93-4, Stud that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. The Standard Recovery SCR type for thyristor properties. Maximum gate trigger voltage 3 V for SCR devices. The voltage 1.2 kV when the device is not active for switches or semiconductors. The highest voltage drop Vtm 1.55 V in the active state for semiconductors.
