Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 30 | ₹ 6,862.14000 | ₹ 2,05,864.20 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Off-State Voltage Rating | 700 V | |
| Max Gate Trigger Volts | 3 V | |
| Max Gate Trigger Amps | 150 mA | |
| Max On-State Voltage Drop | 2.6 V | |
| Max Average On-State Current | - | |
| Max RMS On-State Current | 100 A | |
| Maximum Holding Current | 500 mA | |
| Maximum Off-State Current | 10 mA | |
| Non-Repetitive Surge 50/60Hz | 1400A, 1500A | |
| Silicon Controlled Rectifier Style | Standard Recovery | |
| Ambient Temp Range | -40°C ~ 125°C | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Stud Mount | |
| Component Housing Style | TO-208AD, TO-83-3, Stud | |
| Vendor Package Type | - |
Description
Features a maximum gate trigger current (Igt) rated at 150 mA. Indicates the maximum holding current recorded at 500 mA. Is designed to manage surge current Itsm rated at 1400A, 1500A for 50/60Hz. Features a maximum off-state current of 10 mA. Supports RMS on-state current rated at 100 A. Mounting configuration Stud Mount for structural stability. Temperature range -40°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case TO-208AD, TO-83-3, Stud that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. The Standard Recovery SCR type for thyristor properties. Maximum gate trigger voltage 3 V for SCR devices. The voltage 700 V when the device is not active for switches or semiconductors. The highest voltage drop Vtm 2.6 V in the active state for semiconductors.
