Stock:
Distributor: 135
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 10000 | ₹ 546.46000 | ₹ 54,64,600.00 |
| 1000 | ₹ 581.17000 | ₹ 5,81,170.00 |
| 500 | ₹ 614.99000 | ₹ 3,07,495.00 |
| 100 | ₹ 649.70000 | ₹ 64,970.00 |
| 25 | ₹ 683.52000 | ₹ 17,088.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | BulkTray | |
| Availability Status | Obsolete | |
| Off-State Voltage Rating | 2.2 kV | |
| Max Gate Trigger Volts | 2 V | |
| Max Gate Trigger Amps | 250 mA | |
| Max On-State Voltage Drop | 1.75 V | |
| Max Average On-State Current | 923 A | |
| Max RMS On-State Current | 1000 A | |
| Maximum Holding Current | 500 mA | |
| Maximum Off-State Current | - | |
| Non-Repetitive Surge 50/60Hz | 30000A @ 50Hz | |
| Silicon Controlled Rectifier Style | Standard Recovery | |
| Ambient Temp Range | 135°C (TJ) | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module | |
| Vendor Package Type | BG-PB70ECO-1 |
Description
Features a maximum gate trigger current (Igt) rated at 250 mA. Indicates the maximum holding current recorded at 500 mA. Is designed to manage surge current Itsm rated at 30000A @ 50Hz for 50/60Hz. Offers a maximum average on-state current It(AV) of 923 A. Supports RMS on-state current rated at 1000 A. Mounting configuration Chassis Mount for structural stability. Temperature range 135°C (TJ) for environmental conditions impacting thermal efficiency. Type of housing BulkTray for safeguarding or transporting components. Style of the enclosure/case Module that offers mechanical and thermal protection. Type of package BG-PB70ECO-1 that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. The Standard Recovery SCR type for thyristor properties. Supplier package type BG-PB70ECO-1 for component selection. Maximum gate trigger voltage 2 V for SCR devices. The voltage 2.2 kV when the device is not active for switches or semiconductors. The highest voltage drop Vtm 1.75 V in the active state for semiconductors.
