Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | XCL214 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 2.7V | |
| Maximum Input Voltage | 5.5V | |
| First Rail Output Volts | 2.5V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 1.5A | |
| Wattage Power Level | - | |
| Isolation Barrier Voltage | - | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | OCP, OTP, SCP, UVLO | |
| Ambient Temp Range | -40°C ~ 105°C | |
| Performance Efficiency Rating | 92% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 9-PowerTFQFN | |
| Package Size Specs | 0.13" L x 0.10" W x 0.04" H (3.2mm x 2.5mm x 1.0mm) | |
| Vendor Package Type | USP-9B01 | |
| Adjustment Capabilities | - | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Supplies peak output current defined as 1.5A. Offers an efficiency rating calculated at 92%. Equipped with features categorized as OCP, OTP, SCP, UVLO. The input voltage established at 2.7V for reliable performance. Mounting configuration Surface Mount for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 105°C for environmental conditions impacting thermal efficiency. Voltage 2.5V for optimal output electric potential. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 9-PowerTFQFN that offers mechanical and thermal protection. Type of package USP-9B01 that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component XCL214. Details on package size 0.13" L x 0.10" W x 0.04" H (3.2mm x 2.5mm x 1.0mm) for electrical or mechanical components. Measurement dimensions 0.13" L x 0.10" W x 0.04" H (3.2mm x 2.5mm x 1.0mm) for component specifications. Supplier package type USP-9B01 for component selection. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 5.5V for safeguarding. Minimum input voltage 2.7V for operation. Output 1 voltage 2.5V across different outputs.
