Stock:
Distributor: 11
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 500 | ₹ 118.37000 | ₹ 59,185.00 |
| 250 | ₹ 121.93000 | ₹ 30,482.50 |
| 100 | ₹ 135.28000 | ₹ 13,528.00 |
| 50 | ₹ 145.07000 | ₹ 7,253.50 |
| 25 | ₹ 154.86000 | ₹ 3,871.50 |
| 10 | ₹ 169.10000 | ₹ 1,691.00 |
| 1 | ₹ 217.16000 | ₹ 217.16 |
Stock:
Distributor: 121
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 225.58000 | ₹ 225.58 |
| 10 | ₹ 157.38000 | ₹ 1,573.80 |
| 50 | ₹ 149.51000 | ₹ 7,475.50 |
| 100 | ₹ 141.64000 | ₹ 14,164.00 |
| 250 | ₹ 137.27000 | ₹ 34,317.50 |
| 500 | ₹ 126.78000 | ₹ 63,390.00 |
| 1000 | ₹ 114.54000 | ₹ 1,14,540.00 |
| 2500 | ₹ 104.92000 | ₹ 2,62,300.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | XCL103 | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Active | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 0.9V | |
| Maximum Input Voltage | 6V | |
| First Rail Output Volts | 3.234 ~ 3.366V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 350mA | |
| Wattage Power Level | 1.2 W | |
| Isolation Barrier Voltage | - | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | OCP, SCP | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Performance Efficiency Rating | 86% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | - | |
| Package Size Specs | 0.10" L x 0.08" W x 0.04" H (2.5mm x 2.0mm x 1.0mm) | |
| Vendor Package Type | CL-2025-02 | |
| Adjustment Capabilities | - | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Supplies peak output current defined as 350mA. Offers an efficiency rating calculated at 86%. Equipped with features categorized as OCP, SCP. The input voltage established at 0.9V for reliable performance. Mounting configuration Surface Mount for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Voltage 3.234 ~ 3.366V for optimal output electric potential. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Type of package CL-2025-02 that preserves the integrity of the device. Power measured in watts 1.2 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component XCL103. Details on package size 0.10" L x 0.08" W x 0.04" H (2.5mm x 2.0mm x 1.0mm) for electrical or mechanical components. Measurement dimensions 0.10" L x 0.08" W x 0.04" H (2.5mm x 2.0mm x 1.0mm) for component specifications. Supplier package type CL-2025-02 for component selection. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 6V for safeguarding. Minimum input voltage 0.9V for operation. Output 1 voltage 3.234 ~ 3.366V across different outputs.
