Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | AG7010 | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 8V | |
| Maximum Input Voltage | 24V | |
| First Rail Output Volts | 3 ~ 12.7V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 10A | |
| Wattage Power Level | 127 W | |
| Isolation Barrier Voltage | - | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | Adjustable Output, PMBus™ | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Performance Efficiency Rating | 97% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 12-SMD Module | |
| Package Size Specs | 1.47" L x 0.57" W x 0.32" H (37.4mm x 14.4mm x 8.2mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | - | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Supplies peak output current defined as 10A. Offers an efficiency rating calculated at 97%. Equipped with features categorized as Adjustable Output, PMBus™. The input voltage established at 8V for reliable performance. Mounting configuration Surface Mount for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Voltage 3 ~ 12.7V for optimal output electric potential. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 12-SMD Module that offers mechanical and thermal protection. Power measured in watts 127 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component AG7010. Details on package size 1.47" L x 0.57" W x 0.32" H (37.4mm x 14.4mm x 8.2mm) for electrical or mechanical components. Measurement dimensions 1.47" L x 0.57" W x 0.32" H (37.4mm x 14.4mm x 8.2mm) for component specifications. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 24V for safeguarding. Minimum input voltage 8V for operation. Output 1 voltage 3 ~ 12.7V across different outputs.
