Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | EHD-RD | |
| IC Encapsulation Type | Tray | |
| Availability Status | Obsolete | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 113V | |
| Maximum Input Voltage | 170V | |
| First Rail Output Volts | 20V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 100mA | |
| Wattage Power Level | 2 W | |
| Isolation Barrier Voltage | - | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | - | |
| Ambient Temp Range | -25°C ~ 85°C | |
| Performance Efficiency Rating | 75% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 10-SIP Module, 9 Leads | |
| Package Size Specs | 1.20" L x 0.39" W x 0.74" H (30.5mm x 10.0mm x 18.9mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | - | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Supplies peak output current defined as 100mA. Offers an efficiency rating calculated at 75%. The input voltage established at 113V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 1 for device connections. Temperature range -25°C ~ 85°C for environmental conditions impacting thermal efficiency. Voltage 20V for optimal output electric potential. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 10-SIP Module, 9 Leads that offers mechanical and thermal protection. Power measured in watts 2 W for optimal operation. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component EHD-RD. Details on package size 1.20" L x 0.39" W x 0.74" H (30.5mm x 10.0mm x 18.9mm) for electrical or mechanical components. Measurement dimensions 1.20" L x 0.39" W x 0.74" H (30.5mm x 10.0mm x 18.9mm) for component specifications. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 170V for safeguarding. Minimum input voltage 113V for operation. Output 1 voltage 20V across different outputs.
