Stock:
Distributor: 116
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 288 | ₹ 2,706.71000 | ₹ 7,79,532.48 |
| 216 | ₹ 2,751.43000 | ₹ 5,94,308.88 |
| 144 | ₹ 2,790.43000 | ₹ 4,01,821.92 |
| 72 | ₹ 2,830.55000 | ₹ 2,03,799.60 |
| 36 | ₹ 2,887.16000 | ₹ 1,03,937.76 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | Hammerhead™ EHHD010A0B (120W) | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Device Type Classification | Isolated Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 75V | |
| First Rail Output Volts | 12V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 10A | |
| Wattage Power Level | 120 W | |
| Isolation Barrier Voltage | 2.25 kV | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Performance Efficiency Rating | 93% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 8-DIP Module, 1/8 Brick | |
| Package Size Specs | 2.30" L x 0.90" W x 0.35" H (58.4mm x 22.9mm x 8.9mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | Enable, Active Low | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
