Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 120 | ₹ 4,215.57000 | ₹ 5,05,868.40 |
| 80 | ₹ 4,256.30000 | ₹ 3,40,504.00 |
| 40 | ₹ 4,326.80000 | ₹ 1,73,072.00 |
| 10 | ₹ 4,471.09000 | ₹ 44,710.90 |
| 5 | ₹ 4,544.85000 | ₹ 22,724.25 |
| 1 | ₹ 4,720.36000 | ₹ 4,720.36 |
Stock:
Distributor: 114
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 40 | ₹ 4,416.18000 | ₹ 1,76,647.20 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | EPM25-2V (60W) | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Device Type Classification | Isolated Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 9V | |
| Maximum Input Voltage | 36V | |
| First Rail Output Volts | 15V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 4A | |
| Wattage Power Level | 60 W | |
| Isolation Barrier Voltage | 1.6 kV | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | Adjustable Output, Remote On/Off | |
| Ambient Temp Range | -40°C ~ 105°C (With Derating) | |
| Performance Efficiency Rating | 92% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 6-DIP Module | |
| Package Size Specs | 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | - | |
| Certification Body | - | |
| Compliance Standard ID | 62368-1 |
Description
Perfectly designed for situations involving ITE (Commercial). Supplies peak output current defined as 4A. Offers an efficiency rating calculated at 92%. Equipped with features categorized as Adjustable Output, Remote On/Off. The input voltage established at 9V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 105°C (With Derating) for environmental conditions impacting thermal efficiency. Voltage 15V for optimal output electric potential. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 6-DIP Module that offers mechanical and thermal protection. Power measured in watts 60 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component EPM25-2V (60W). Details on package size 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm) for electrical or mechanical components. Measurement dimensions 2.00" L x 1.00" W x 0.41" H (50.8mm x 25.4mm x 10.5mm) for component specifications. Standard compliance code 62368-1 for regulations. Type classification Isolated Module for specifications. Maximum input voltage 36V for safeguarding. Minimum input voltage 9V for operation. Isolation voltage 1.6 kV for electrical safety. Output 1 voltage 15V across different outputs.
