Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | PH02S/D (2W) | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| Device Type Classification | Isolated Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 75V | |
| First Rail Output Volts | 5V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 400mA | |
| Wattage Power Level | 2 W | |
| Isolation Barrier Voltage | 1.5 kV | |
| Intended Uses | Medical | |
| Key Product Highlights | Remote On/Off, SCP, UVLO | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Performance Efficiency Rating | 72% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 9-SIP Module, 7 Leads | |
| Package Size Specs | 1.02" L x 0.36" W x 0.49" H (25.9mm x 9.1mm x 12.4mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | Enable, Active Low | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving Medical. Is equipped with control features recognized as Enable, Active Low. Supplies peak output current defined as 400mA. Offers an efficiency rating calculated at 72%. Equipped with features categorized as Remote On/Off, SCP, UVLO. The input voltage established at 18V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Voltage 5V for optimal output electric potential. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 9-SIP Module, 7 Leads that offers mechanical and thermal protection. Power measured in watts 2 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component PH02S/D (2W). Details on package size 1.02" L x 0.36" W x 0.49" H (25.9mm x 9.1mm x 12.4mm) for electrical or mechanical components. Measurement dimensions 1.02" L x 0.36" W x 0.49" H (25.9mm x 9.1mm x 12.4mm) for component specifications. Type classification Isolated Module for specifications. Maximum input voltage 75V for safeguarding. Minimum input voltage 18V for operation. Isolation voltage 1.5 kV for electrical safety. Output 1 voltage 5V across different outputs.
