Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Delphi D12S400 | |
| IC Encapsulation Type | Tray | |
| Availability Status | Active | |
| Device Type Classification | Non-Isolated PoL Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 5V | |
| Maximum Input Voltage | 13.2V | |
| First Rail Output Volts | 0.84 ~ 5V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 80A | |
| Wattage Power Level | 400 W | |
| Isolation Barrier Voltage | - | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | Remote On/Off, OCP, OTP, OVP, UVLO | |
| Ambient Temp Range | 0°C ~ 85°C | |
| Performance Efficiency Rating | 94% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 24-SIP Module | |
| Package Size Specs | 2.40" L x 0.66" W x 1.25" H (61.0mm x 16.7mm x 31.8mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | Enable, Active High | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Is equipped with control features recognized as Enable, Active High. Supplies peak output current defined as 80A. Offers an efficiency rating calculated at 94%. Equipped with features categorized as Remote On/Off, OCP, OTP, OVP, UVLO. The input voltage established at 5V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 1 for device connections. Temperature range 0°C ~ 85°C for environmental conditions impacting thermal efficiency. Voltage 0.84 ~ 5V for optimal output electric potential. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 24-SIP Module that offers mechanical and thermal protection. Power measured in watts 400 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component Delphi D12S400. Details on package size 2.40" L x 0.66" W x 1.25" H (61.0mm x 16.7mm x 31.8mm) for electrical or mechanical components. Measurement dimensions 2.40" L x 0.66" W x 1.25" H (61.0mm x 16.7mm x 31.8mm) for component specifications. Type classification Non-Isolated PoL Module for specifications. Maximum input voltage 13.2V for safeguarding. Minimum input voltage 5V for operation. Output 1 voltage 0.84 ~ 5V across different outputs.
