Stock:
Distributor: 113
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ₹ 5,387.70000 | ₹ 5,387.70 |
| 5 | ₹ 4,976.52000 | ₹ 24,882.60 |
| 10 | ₹ 4,767.20000 | ₹ 47,672.00 |
| 25 | ₹ 4,660.04000 | ₹ 1,16,501.00 |
| 50 | ₹ 4,550.39000 | ₹ 2,27,519.50 |
| 126 | ₹ 4,515.50000 | ₹ 5,68,953.00 |
| 252 | ₹ 4,474.39000 | ₹ 11,27,546.28 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Delphi E48SH (120W) | |
| IC Encapsulation Type | Tray | |
| Availability Status | Not For New Designs | |
| Device Type Classification | Isolated Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 36V | |
| Maximum Input Voltage | 75V | |
| First Rail Output Volts | 12V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 10A | |
| Wattage Power Level | 120 W | |
| Isolation Barrier Voltage | 2.25 kV | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | Remote On/Off, OCP, OTP, OVP, UVLO | |
| Ambient Temp Range | -40°C ~ 123°C | |
| Performance Efficiency Rating | 93.1% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 8-DIP Module, 1/8 Brick | |
| Package Size Specs | 2.30" L x 0.90" W x 0.37" H (58.4mm x 22.9mm x 9.4mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | Enable, Active Low | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Is equipped with control features recognized as Enable, Active Low. Supplies peak output current defined as 10A. Offers an efficiency rating calculated at 93.1%. Equipped with features categorized as Remote On/Off, OCP, OTP, OVP, UVLO. The input voltage established at 36V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 123°C for environmental conditions impacting thermal efficiency. Voltage 12V for optimal output electric potential. Type of housing Tray for safeguarding or transporting components. Style of the enclosure/case 8-DIP Module, 1/8 Brick that offers mechanical and thermal protection. Power measured in watts 120 W for optimal operation. Product status Not For New Designs concerning availability and lifecycle. Classification series for the product or component Delphi E48SH (120W). Details on package size 2.30" L x 0.90" W x 0.37" H (58.4mm x 22.9mm x 9.4mm) for electrical or mechanical components. Measurement dimensions 2.30" L x 0.90" W x 0.37" H (58.4mm x 22.9mm x 9.4mm) for component specifications. Type classification Isolated Module for specifications. Maximum input voltage 75V for safeguarding. Minimum input voltage 36V for operation. Isolation voltage 2.25 kV for electrical safety. Output 1 voltage 12V across different outputs.
