Stock:
Distributor: 116
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 48 | ₹ 15,331.51000 | ₹ 7,35,912.48 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | VHE100W (100W) | |
| IC Encapsulation Type | BulkBox | |
| Availability Status | Active | |
| Device Type Classification | Isolated Module | |
| Signal Output Quantity | 1 | |
| Minimum Input Voltage | 18V | |
| Maximum Input Voltage | 75V | |
| First Rail Output Volts | 24V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 4.2A | |
| Wattage Power Level | 100 W | |
| Isolation Barrier Voltage | 1.5 kV | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | Remote On/Off, OCP, OTP, OVP, SCP, UVLO | |
| Ambient Temp Range | -40°C ~ 105°C | |
| Performance Efficiency Rating | 91% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 9-DIP Module | |
| Package Size Specs | 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | Enable, Active High | |
| Certification Body | EN | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Complies with the criteria of entities acknowledged as EN. Is equipped with control features recognized as Enable, Active High. Supplies peak output current defined as 4.2A. Offers an efficiency rating calculated at 91%. Equipped with features categorized as Remote On/Off, OCP, OTP, OVP, SCP, UVLO. The input voltage established at 18V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 105°C for environmental conditions impacting thermal efficiency. Voltage 24V for optimal output electric potential. Type of housing BulkBox for safeguarding or transporting components. Style of the enclosure/case 9-DIP Module that offers mechanical and thermal protection. Power measured in watts 100 W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component VHE100W (100W). Details on package size 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) for electrical or mechanical components. Measurement dimensions 2.40" L x 2.28" W x 0.50" H (61.0mm x 57.9mm x 12.7mm) for component specifications. Type classification Isolated Module for specifications. Maximum input voltage 75V for safeguarding. Minimum input voltage 18V for operation. Isolation voltage 1.5 kV for electrical safety. Output 1 voltage 24V across different outputs.
