Stock:
Distributor: 110
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 7500 | ₹ 240.30000 | ₹ 18,02,250.00 |
| 5000 | ₹ 243.86000 | ₹ 12,19,300.00 |
| 2500 | ₹ 247.42000 | ₹ 6,18,550.00 |
| 1000 | ₹ 257.21000 | ₹ 2,57,210.00 |
| 500 | ₹ 261.66000 | ₹ 1,30,830.00 |
| 250 | ₹ 280.35000 | ₹ 70,087.50 |
| 100 | ₹ 307.05000 | ₹ 30,705.00 |
| 25 | ₹ 316.84000 | ₹ 7,921.00 |
Stock:
Distributor: 111
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 2 | ₹ 256.50000 | ₹ 513.00 |
Stock:
Distributor: 122
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 500 | ₹ 293.69000 | ₹ 1,46,845.00 |
| 250 | ₹ 293.96000 | ₹ 73,490.00 |
| 100 | ₹ 304.02000 | ₹ 30,402.00 |
| 50 | ₹ 311.87000 | ₹ 15,593.50 |
| 25 | ₹ 319.90000 | ₹ 7,997.50 |
| 10 | ₹ 330.87000 | ₹ 3,308.70 |
| 5 | ₹ 339.48000 | ₹ 1,697.40 |
| 1 | ₹ 359.73000 | ₹ 359.73 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| Device Type Classification | Isolated Module | |
| Signal Output Quantity | 2 | |
| Minimum Input Voltage | 21.6V | |
| Maximum Input Voltage | 26.4V | |
| First Rail Output Volts | 3.3V | |
| Second Rail Output Volts | -10V | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Peak Output Current | 150mA, 150mA | |
| Wattage Power Level | 3 W | |
| Isolation Barrier Voltage | 1.5 kV | |
| Intended Uses | ITE (Commercial) | |
| Key Product Highlights | - | |
| Ambient Temp Range | -40°C ~ 105°C (With Derating) | |
| Performance Efficiency Rating | 86% | |
| Quality Grade Level | - | |
| Certification Qualification | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 7-SIP Module, 5 Leads | |
| Package Size Specs | 0.77" L x 0.28" W x 0.39" H (19.5mm x 7.1mm x 10.0mm) | |
| Vendor Package Type | - | |
| Adjustment Capabilities | - | |
| Certification Body | - | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Supplies peak output current defined as 150mA, 150mA. Offers an efficiency rating calculated at 86%. The input voltage established at 21.6V for reliable performance. Mounting configuration Through Hole for structural stability. Overall outputs 2 for device connections. Temperature range -40°C ~ 105°C (With Derating) for environmental conditions impacting thermal efficiency. Voltage 3.3V for optimal output electric potential. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 7-SIP Module, 5 Leads that offers mechanical and thermal protection. Power measured in watts 3 W for optimal operation. Product status Active concerning availability and lifecycle. Details on package size 0.77" L x 0.28" W x 0.39" H (19.5mm x 7.1mm x 10.0mm) for electrical or mechanical components. Measurement dimensions 0.77" L x 0.28" W x 0.39" H (19.5mm x 7.1mm x 10.0mm) for component specifications. Type classification Isolated Module for specifications. Maximum input voltage 26.4V for safeguarding. Minimum input voltage 21.6V for operation. Isolation voltage 1.5 kV for electrical safety. Output 1 voltage 3.3V across different outputs. Output 2 voltage -10V across different outputs.
