Stock:
Distributor: 116
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1600 | ₹ 45,608.73000 | ₹ 7,29,73,968.00 |
| 800 | ₹ 52,171.36000 | ₹ 4,17,37,088.00 |
| 400 | ₹ 52,441.67000 | ₹ 2,09,76,668.00 |
| 200 | ₹ 52,711.99000 | ₹ 1,05,42,398.00 |
| 100 | ₹ 52,982.31000 | ₹ 52,98,231.00 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | Tariff may apply if shipping to the United States | |
| Product Series Line | D1U86P-W-1600 (1600W) | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Device Type Classification | Front End | |
| Signal Output Quantity | 1 | |
| Supply Input Volts | 90 ~ 264 VAC | |
| First Rail Output Volts | 12V | |
| Second Rail Output Volts | - | |
| Third Rail Output Volts | - | |
| Fourth Rail Output Volts | - | |
| Fifth Rail Output Volts | - | |
| Sixth Rail Output Volts | - | |
| First Output Current | 133.3 A | |
| Second Output Current | - | |
| Third Output Current | - | |
| Fourth Output Current | - | |
| Fifth Output Current | - | |
| Sixth Output Current | - | |
| Wattage Power Level | 1600W | |
| Intended Uses | ITE (Commercial) | |
| Isolation Barrier Voltage | 3 kV | |
| Performance Efficiency Rating | 94% | |
| Ambient Temp Range | -40°C ~ 85°C (With Derating) | |
| Key Product Highlights | Hot Swappable, I2C Interface, Load Sharing, PFC, PMBus™, Remote On/Off, Standby Output, Universal Input | |
| Attachment Mounting Style | Rack Mount | |
| Package Size Specs | 7.75" L x 3.40" W x 1.57" H (196.9mm x 86.4mm x 39.9mm) | |
| Certification Body | CB, cCSAus, CE, TUVgs | |
| Compliance Standard ID | - |
Description
Perfectly designed for situations involving ITE (Commercial). Complies with the criteria of entities acknowledged as CB, cCSAus, CE, TUVgs. Assesses resistance at forward current Tariff may apply if shipping to the United States for LED or diode testing. Represents the current for output 1 set to 133.3 A. Offers an efficiency rating calculated at 94%. Equipped with features categorized as Hot Swappable, I2C Interface, Load Sharing, PFC, PMBus™, Remote On/Off, Standby Output, Universal Input. The input voltage established at 90 ~ 264 VAC for reliable performance. Mounting configuration Rack Mount for structural stability. Overall outputs 1 for device connections. Temperature range -40°C ~ 85°C (With Derating) for environmental conditions impacting thermal efficiency. Voltage 12V for optimal output electric potential. Type of housing Box for safeguarding or transporting components. Power measured in watts 1600W for optimal operation. Product status Active concerning availability and lifecycle. Classification series for the product or component D1U86P-W-1600 (1600W). Details on package size 7.75" L x 3.40" W x 1.57" H (196.9mm x 86.4mm x 39.9mm) for electrical or mechanical components. Measurement dimensions 7.75" L x 3.40" W x 1.57" H (196.9mm x 86.4mm x 39.9mm) for component specifications. Current supply level 90 ~ 264 VAC for electrical parameters. The classification for import duties Tariff may apply if shipping to the United States related to import and export transactions. Type classification Front End for specifications. Maximum Vce(on) at Vge Tariff may apply if shipping to the United States for transistor specifications. Input voltage 90 ~ 264 VAC required for devices. Isolation voltage 3 kV for electrical safety. Output 1 voltage 12V across different outputs.
