Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 250 | ₹ 495.95000 | ₹ 1,23,987.50 |
| 100 | ₹ 500.51000 | ₹ 50,051.00 |
| 50 | ₹ 535.57000 | ₹ 26,778.50 |
| 30 | ₹ 562.49000 | ₹ 16,874.70 |
| 10 | ₹ 622.72000 | ₹ 6,227.20 |
| 1 | ₹ 753.49000 | ₹ 753.49 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | FAD1-08025-A | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Rated Operating Voltage | 24VDC | |
| Package Size Specs | Square - 80mm L x 80mm H | |
| Horizontal Width Dimension | 25.00mm | |
| Ventilation Rate | 37.2 CFM (1.04m³/min) | |
| Airflow Static Pressure | 0.157 in H2O (39.1 Pa) | |
| Rotary Bearing Design | Ball | |
| Airflow Fan Category | Tubeaxial | |
| Key Product Highlights | - | |
| Electrical Noise Level | 35.8dB(A) | |
| Wattage Power Level | 2.4 W | |
| Revolutions Per Minute | 3000 RPM | |
| Circuit End Method | 2 Wire Leads | |
| Dust Water Resistance Rating | - | |
| Ambient Temp Range | 14 ~ 158°F (-10 ~ 70°C) | |
| Certification Body | CE, cURus, TUV | |
| Product Weight Grams | 0.159 lb (72.12 g) |
Description
Delivers airflow rated at 37.2 CFM (1.04m³/min) for optimal cooling efficiency. Complies with the criteria of entities acknowledged as CE, cURus, TUV. Equipped with a Ball type bearing for reliable mechanical rotation. Facilitates a maximum output current level set as 0.157 in H2O (39.1 Pa). Specifies the fan type categorized as Tubeaxial. Noise level measurement 35.8dB(A) for sound or electronic quality. Temperature range 14 ~ 158°F (-10 ~ 70°C) for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Power measured in watts 2.4 W for optimal operation. Product status Active concerning availability and lifecycle. The RPM value 3000 RPM for motors or mechanical devices. Classification series for the product or component FAD1-08025-A. Details on package size Square - 80mm L x 80mm H for electrical or mechanical components. Measurement dimensions Square - 80mm L x 80mm H for component specifications. Static pressure value 0.157 in H2O (39.1 Pa) for air or fluid systems. Termination method 2 Wire Leads for electrical or mechanical connections. The operating voltage rating of the device 24VDC. Weight 0.159 lb (72.12 g) for product specifications. Horizontal width measurement 25.00mm.
