Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | AFB | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Rated Operating Voltage | 12VDC | |
| Package Size Specs | Square - 80mm L x 80mm H | |
| Horizontal Width Dimension | 25.40mm | |
| Ventilation Rate | 46.6 CFM (1.30m³/min) | |
| Airflow Static Pressure | 0.267 in H2O (66.5 Pa) | |
| Rotary Bearing Design | Ball | |
| Airflow Fan Category | Tubeaxial | |
| Key Product Highlights | Locked Rotor Sensor | |
| Electrical Noise Level | 40.0dB(A) | |
| Wattage Power Level | 4.08 W | |
| Revolutions Per Minute | 4000 RPM | |
| Circuit End Method | 3 Wire Leads | |
| Dust Water Resistance Rating | - | |
| Ambient Temp Range | 14 ~ 158°F (-10 ~ 70°C) | |
| Certification Body | CE, CSA, UL, VDE | |
| Product Weight Grams | 0.176 lb (79.83 g) |
Description
Delivers airflow rated at 46.6 CFM (1.30m³/min) for optimal cooling efficiency. Complies with the criteria of entities acknowledged as CE, CSA, UL, VDE. Equipped with a Ball type bearing for reliable mechanical rotation. Facilitates a maximum output current level set as 0.267 in H2O (66.5 Pa). Specifies the fan type categorized as Tubeaxial. Equipped with features categorized as Locked Rotor Sensor. Noise level measurement 40.0dB(A) for sound or electronic quality. Temperature range 14 ~ 158°F (-10 ~ 70°C) for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Power measured in watts 4.08 W for optimal operation. Product status Obsolete concerning availability and lifecycle. The RPM value 4000 RPM for motors or mechanical devices. Classification series for the product or component AFB. Details on package size Square - 80mm L x 80mm H for electrical or mechanical components. Measurement dimensions Square - 80mm L x 80mm H for component specifications. Static pressure value 0.267 in H2O (66.5 Pa) for air or fluid systems. Termination method 3 Wire Leads for electrical or mechanical connections. The operating voltage rating of the device 12VDC. Weight 0.176 lb (79.83 g) for product specifications. Horizontal width measurement 25.40mm.
