Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | GTW | |
| IC Encapsulation Type | Box | |
| Availability Status | Obsolete | |
| Rated Operating Voltage | 230VAC | |
| Package Size Specs | Round - 528mm Dia | |
| Horizontal Width Dimension | 154.0mm | |
| Ventilation Rate | 3147.0 CFM (88.12m³/min) | |
| Airflow Static Pressure | 0.710 in H2O (176.9 Pa) | |
| Rotary Bearing Design | Ball | |
| Airflow Fan Category | Tubeaxial | |
| Key Product Highlights | PWM Control, Thermal Overload Protector (TOP) | |
| Electrical Noise Level | 72.0dB(A) | |
| Wattage Power Level | 330W | |
| Revolutions Per Minute | 1650 RPM | |
| Circuit End Method | - | |
| Dust Water Resistance Rating | IP54 - Dust Protected, Water Resistant | |
| Ambient Temp Range | -13 ~ 140°F (-25 ~ 60°C) | |
| Certification Body | cUL, TUV | |
| Product Weight Grams | 21 lbs (9.5 kg) |
Description
Delivers airflow rated at 3147.0 CFM (88.12m³/min) for optimal cooling efficiency. Complies with the criteria of entities acknowledged as cUL, TUV. Equipped with a Ball type bearing for reliable mechanical rotation. Facilitates a maximum output current level set as 0.710 in H2O (176.9 Pa). Specifies the fan type categorized as Tubeaxial. Equipped with features categorized as PWM Control, Thermal Overload Protector (TOP). Rated with IP IP54 - Dust Protected, Water Resistant to safeguard against dust and moisture penetration. Noise level measurement 72.0dB(A) for sound or electronic quality. Temperature range -13 ~ 140°F (-25 ~ 60°C) for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Power measured in watts 330W for optimal operation. Product status Obsolete concerning availability and lifecycle. The RPM value 1650 RPM for motors or mechanical devices. Classification series for the product or component GTW. Details on package size Round - 528mm Dia for electrical or mechanical components. Measurement dimensions Round - 528mm Dia for component specifications. Static pressure value 0.710 in H2O (176.9 Pa) for air or fluid systems. The operating voltage rating of the device 230VAC. Weight 21 lbs (9.5 kg) for product specifications. Horizontal width measurement 154.0mm.
