Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 25 | ₹ 17,963.08000 | ₹ 4,49,077.00 |
| 10 | ₹ 18,342.49000 | ₹ 1,83,424.90 |
| 1 | ₹ 22,797.63000 | ₹ 22,797.63 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | GTW | |
| IC Encapsulation Type | Box | |
| Availability Status | Obsolete | |
| Rated Operating Voltage | 230VAC | |
| Package Size Specs | Round - 200mm Dia | |
| Horizontal Width Dimension | 122.0mm | |
| Ventilation Rate | 636.0 CFM (17.81m³/min) | |
| Airflow Static Pressure | 4.163 in H2O (1037.0 Pa) | |
| Rotary Bearing Design | Ball | |
| Airflow Fan Category | Tubeaxial | |
| Key Product Highlights | PWM Control, Speed Sensor (Tach) | |
| Electrical Noise Level | 70.0dB(A) | |
| Wattage Power Level | 240W | |
| Revolutions Per Minute | 6000 RPM | |
| Circuit End Method | - | |
| Dust Water Resistance Rating | IP54 - Dust Protected, Water Resistant | |
| Ambient Temp Range | -13 ~ 140°F (-25 ~ 60°C) | |
| Certification Body | TUV, UL | |
| Product Weight Grams | 6 lbs (2.7 kg) |
Description
Delivers airflow rated at 636.0 CFM (17.81m³/min) for optimal cooling efficiency. Complies with the criteria of entities acknowledged as TUV, UL. Equipped with a Ball type bearing for reliable mechanical rotation. Facilitates a maximum output current level set as 4.163 in H2O (1037.0 Pa). Specifies the fan type categorized as Tubeaxial. Equipped with features categorized as PWM Control, Speed Sensor (Tach). Rated with IP IP54 - Dust Protected, Water Resistant to safeguard against dust and moisture penetration. Noise level measurement 70.0dB(A) for sound or electronic quality. Temperature range -13 ~ 140°F (-25 ~ 60°C) for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Power measured in watts 240W for optimal operation. Product status Obsolete concerning availability and lifecycle. The RPM value 6000 RPM for motors or mechanical devices. Classification series for the product or component GTW. Details on package size Round - 200mm Dia for electrical or mechanical components. Measurement dimensions Round - 200mm Dia for component specifications. Static pressure value 4.163 in H2O (1037.0 Pa) for air or fluid systems. The operating voltage rating of the device 230VAC. Weight 6 lbs (2.7 kg) for product specifications. Horizontal width measurement 122.0mm.
