Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 72 | ₹ 2,845.85000 | ₹ 2,04,901.20 |
| 36 | ₹ 2,861.86000 | ₹ 1,03,026.96 |
| 10 | ₹ 3,240.20000 | ₹ 32,402.00 |
| 1 | ₹ 3,977.65000 | ₹ 3,977.65 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | AFL, EST | |
| IC Encapsulation Type | Box | |
| Availability Status | Active | |
| Rated Operating Voltage | 100 ~ 240VAC | |
| Package Size Specs | Square - 120mm L x 120mm H | |
| Horizontal Width Dimension | 38.00mm | |
| Ventilation Rate | 103.6 CFM (2.90m³/min) | |
| Airflow Static Pressure | 0.400 in H2O (99.6 Pa) | |
| Rotary Bearing Design | Ball | |
| Airflow Fan Category | Tubeaxial | |
| Key Product Highlights | Electronic Commutation (EC), Locked Rotor Protection | |
| Electrical Noise Level | 45.0dB(A) | |
| Wattage Power Level | 4.60W | |
| Revolutions Per Minute | 3200 RPM | |
| Circuit End Method | 2 Wire Leads | |
| Dust Water Resistance Rating | IP52 | |
| Ambient Temp Range | -4 ~ 140°F (-20 ~ 60°C) | |
| Certification Body | - | |
| Product Weight Grams | - |
Description
Delivers airflow rated at 103.6 CFM (2.90m³/min) for optimal cooling efficiency. Equipped with a Ball type bearing for reliable mechanical rotation. Facilitates a maximum output current level set as 0.400 in H2O (99.6 Pa). Specifies the fan type categorized as Tubeaxial. Equipped with features categorized as Electronic Commutation (EC), Locked Rotor Protection. Rated with IP IP52 to safeguard against dust and moisture penetration. Noise level measurement 45.0dB(A) for sound or electronic quality. Temperature range -4 ~ 140°F (-20 ~ 60°C) for environmental conditions impacting thermal efficiency. Type of housing Box for safeguarding or transporting components. Power measured in watts 4.60W for optimal operation. Product status Active concerning availability and lifecycle. The RPM value 3200 RPM for motors or mechanical devices. Classification series for the product or component AFL, EST. Details on package size Square - 120mm L x 120mm H for electrical or mechanical components. Measurement dimensions Square - 120mm L x 120mm H for component specifications. Static pressure value 0.400 in H2O (99.6 Pa) for air or fluid systems. Termination method 2 Wire Leads for electrical or mechanical connections. The operating voltage rating of the device 100 ~ 240VAC. Horizontal width measurement 38.00mm.
