Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | TACmicrochip®, TAC | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Storage Capacity Electrical | 22 µF | |
| Accuracy Tolerance Percentage | ±10% | |
| Rated Operating Voltage | 6.3 V | |
| Device Type Classification | Molded | |
| Series Resistance Equivalent | 5Ohm | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Expected Life at Temperature | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 0805 (2012 Metric) | |
| Package Size Specs | 0.079" L x 0.053" W (2.00mm x 1.35mm) | |
| Maximum Mounted Height | 0.059" (1.50mm) | |
| Pin Lead Gap | - | |
| Vendor Dimension Code | R | |
| Performance Rating Specs | - | |
| Key Product Highlights | General Purpose | |
| Reliability Failure Metric | - | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Provides a capacitance level rated at 22 µF to maintain circuit stability. Displays ESR rated at 5Ohm. Equipped with features categorized as General Purpose. Maximum installed height of 0.059" (1.50mm) for components affixed to the board. Vendor's dimension code R for uniformity and reference. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 0805 (2012 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component TACmicrochip®, TAC. Details on package size 0.079" L x 0.053" W (2.00mm x 1.35mm) for electrical or mechanical components. Measurement dimensions 0.079" L x 0.053" W (2.00mm x 1.35mm) for component specifications. Precision tolerance level ±10% in manufacturing processes. Type classification Molded for specifications. The operating voltage rating of the device 6.3 V.
