Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | F97 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 15 µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 16 V | |
| Device Type Classification | Molded | |
| Series Resistance Equivalent | 3.5Ohm @ 100kHz | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Expected Life at Temperature | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1206 (3216 Metric) | |
| Package Size Specs | 0.126" L x 0.063" W (3.20mm x 1.60mm) | |
| Maximum Mounted Height | 0.071" (1.80mm) | |
| Pin Lead Gap | - | |
| Vendor Dimension Code | A | |
| Performance Rating Specs | AEC-Q200 | |
| Key Product Highlights | Automotive, High Reliability | |
| Reliability Failure Metric | - | |
| Quality Grade Level | Automotive | |
| Certification Qualification | AEC-Q200 |
Description
Provides a capacitance level rated at 15 µF to maintain circuit stability. Displays ESR rated at 3.5Ohm @ 100kHz. Equipped with features categorized as Automotive, High Reliability. Evaluated as Automotive grade for quality control. Maximum installed height of 0.071" (1.80mm) for components affixed to the board. Vendor's dimension code A for uniformity and reference. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 1206 (3216 Metric) that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Certification AEC-Q200 for compliance with testing or regulatory standards. Criteria AEC-Q200 for electrical, mechanical, or environmental performance. Classification series for the product or component F97. Details on package size 0.126" L x 0.063" W (3.20mm x 1.60mm) for electrical or mechanical components. Measurement dimensions 0.126" L x 0.063" W (3.20mm x 1.60mm) for component specifications. Precision tolerance level ±20% in manufacturing processes. Type classification Molded for specifications. The operating voltage rating of the device 16 V.
