Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | F97 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Storage Capacity Electrical | 10 µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 4 V | |
| Device Type Classification | Molded | |
| Series Resistance Equivalent | 2.1Ohm | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Expected Life at Temperature | - | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1411 (3528 Metric) | |
| Package Size Specs | 0.138" L x 0.110" W (3.50mm x 2.80mm) | |
| Maximum Mounted Height | 0.091" (2.30mm) | |
| Pin Lead Gap | - | |
| Vendor Dimension Code | B | |
| Performance Rating Specs | AEC-Q200 | |
| Key Product Highlights | Automotive, High Reliability | |
| Reliability Failure Metric | - | |
| Quality Grade Level | Automotive | |
| Certification Qualification | AEC-Q200 |
Description
Provides a capacitance level rated at 10 µF to maintain circuit stability. Displays ESR rated at 2.1Ohm. Equipped with features categorized as Automotive, High Reliability. Evaluated as Automotive grade for quality control. Maximum installed height of 0.091" (2.30mm) for components affixed to the board. Vendor's dimension code B for uniformity and reference. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 1411 (3528 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Certification AEC-Q200 for compliance with testing or regulatory standards. Criteria AEC-Q200 for electrical, mechanical, or environmental performance. Classification series for the product or component F97. Details on package size 0.138" L x 0.110" W (3.50mm x 2.80mm) for electrical or mechanical components. Measurement dimensions 0.138" L x 0.110" W (3.50mm x 2.80mm) for component specifications. Precision tolerance level ±20% in manufacturing processes. Type classification Molded for specifications. The operating voltage rating of the device 4 V.
