Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | T502 | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Storage Capacity Electrical | 15 µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 25 V | |
| Device Type Classification | Molded | |
| Series Resistance Equivalent | 700mOhm @ 100kHz | |
| Ambient Temp Range | -55°C ~ 230°C | |
| Expected Life at Temperature | 500 Hrs @ 230°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2917 (7343 Metric) | |
| Package Size Specs | 0.287" L x 0.169" W (7.30mm x 4.30mm) | |
| Maximum Mounted Height | 0.122" (3.10mm) | |
| Pin Lead Gap | - | |
| Vendor Dimension Code | D | |
| Performance Rating Specs | - | |
| Key Product Highlights | High Temperature | |
| Reliability Failure Metric | - | |
| Quality Grade Level | - | |
| Certification Qualification | - |
Description
Provides a capacitance level rated at 15 µF to maintain circuit stability. Displays ESR rated at 700mOhm @ 100kHz. Equipped with features categorized as High Temperature. Maximum installed height of 0.122" (3.10mm) for components affixed to the board. Operates with a durability of 500 Hrs @ 230°C at specified temperature. Vendor's dimension code D for uniformity and reference. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 230°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2917 (7343 Metric) that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component T502. Details on package size 0.287" L x 0.169" W (7.30mm x 4.30mm) for electrical or mechanical components. Measurement dimensions 0.287" L x 0.169" W (7.30mm x 4.30mm) for component specifications. Precision tolerance level ±20% in manufacturing processes. Type classification Molded for specifications. The operating voltage rating of the device 25 V.
