Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | A768, Anti-Vibration | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Active | |
| Device Type Classification | Polymer | |
| Storage Capacity Electrical | 47 µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 80 V | |
| Series Resistance Equivalent | 34mOhm | |
| Expected Life at Temperature | 2000 Hrs @ 125°C | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Performance Rating Specs | AEC-Q200 | |
| Intended Uses | Automotive | |
| Key Product Highlights | Anti-Vibration | |
| Low-Freq Ripple Amps | 90 mA @ 120 Hz | |
| High-Freq Ripple Amps | 1.8 A @ 100 kHz | |
| AC Resistance Value | - | |
| Pin Lead Gap | - | |
| Package Size Specs | 0.394" Dia (10.00mm) | |
| Maximum Mounted Height | 0.520" (13.20mm) | |
| SMD Pad Footprint | 0.425" L x 0.406" W (10.80mm x 10.30mm) | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | Radial, Can - SMD |
Description
Perfectly designed for situations involving Automotive. Provides a capacitance level rated at 47 µF to maintain circuit stability. Facilitates a maximum output current level set as 90 mA @ 120 Hz. Displays ESR rated at 34mOhm. Equipped with features categorized as Anti-Vibration. Maximum installed height of 0.520" (13.20mm) for components affixed to the board. Operates with a durability of 2000 Hrs @ 125°C at specified temperature. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case Radial, Can - SMD that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Criteria AEC-Q200 for electrical, mechanical, or environmental performance. High-frequency ripple current 1.8 A @ 100 kHz for improved performance. Low-frequency ripple current 90 mA @ 120 Hz for improved performance. Classification series for the product or component A768, Anti-Vibration. Details on package size 0.394" Dia (10.00mm) for electrical or mechanical components. Measurement dimensions 0.394" Dia (10.00mm) for component specifications. Dimensions of surface mount pads 0.425" L x 0.406" W (10.80mm x 10.30mm) for PCB design. Precision tolerance level ±20% in manufacturing processes. Type classification Polymer for specifications. The operating voltage rating of the device 80 V.
