Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | OxiCap® NOJ | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 100 µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 6.3 V | |
| Series Resistance Equivalent | 400 mOhms | |
| Leakage Current Amount | 12 µA | |
| Loss Tangent Value | 8% | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 2312 (6032 Metric) | |
| Vendor Dimension Code | F | |
| Maximum Mounted Height | 0.079" (2.00mm) | |
| Key Product Highlights | - | |
| Ambient Temp Range | -55°C ~ 105°C | |
| Vendor Package Type | 2312 (6032 Metric) | |
| Package Size Specs | 0.236" L x 0.126" W (6.00mm x 3.20mm) |
Description
Provides a capacitance level rated at 100 µF to maintain circuit stability. Shows the leakage current noted at 12 µA. Represents the dissipation factor noted at 8%. Displays ESR rated at 400 mOhms. Maximum installed height of 0.079" (2.00mm) for components affixed to the board. Vendor's dimension code F for uniformity and reference. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 105°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case 2312 (6032 Metric) that offers mechanical and thermal protection. Type of package 2312 (6032 Metric) that preserves the integrity of the device. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component OxiCap® NOJ. Details on package size 0.236" L x 0.126" W (6.00mm x 3.20mm) for electrical or mechanical components. Measurement dimensions 0.236" L x 0.126" W (6.00mm x 3.20mm) for component specifications. Supplier package type 2312 (6032 Metric) for component selection. Precision tolerance level ±20% in manufacturing processes. The operating voltage rating of the device 6.3 V.
