Stock:
Distributor: 116
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 48000 | ₹ 20.74000 | ₹ 9,95,520.00 |
| 24000 | ₹ 20.84000 | ₹ 5,00,160.00 |
| 12000 | ₹ 20.96000 | ₹ 2,51,520.00 |
| 6000 | ₹ 21.07000 | ₹ 1,26,420.00 |
| 3000 | ₹ 21.17000 | ₹ 63,510.00 |
Stock:
Distributor: 117
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 9000 | ₹ 21.59000 | ₹ 1,94,310.00 |
| 6000 | ₹ 22.32000 | ₹ 1,33,920.00 |
| 3000 | ₹ 23.72000 | ₹ 71,160.00 |
| 1000 | ₹ 26.73000 | ₹ 26,730.00 |
| 500 | ₹ 28.53000 | ₹ 14,265.00 |
| 100 | ₹ 34.34000 | ₹ 3,434.00 |
| 50 | ₹ 37.77000 | ₹ 1,888.50 |
| 10 | ₹ 48.93000 | ₹ 489.30 |
| 1 | ₹ 77.39000 | ₹ 77.39 |
Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ECH-U(B) | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 3900 pF | |
| Accuracy Tolerance Percentage | ±5% | |
| AC Voltage Max | 30V | |
| DC Voltage Max | 50V | |
| Insulating Dielectric Type | Polyphenylene Sulfide (PPS), Metallized - Stacked | |
| Series Resistance Equivalent | - | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | 1206 (3216 Metric) | |
| Package Size Specs | 0.126" L x 0.063" W (3.20mm x 1.60mm) | |
| Maximum Mounted Height | 0.039" (1.00mm) | |
| Circuit End Method | Solder Pads | |
| Pin Lead Gap | - | |
| Intended Uses | General Purpose | |
| Performance Rating Specs | - | |
| Key Product Highlights | - |
Description
Perfectly designed for situations involving General Purpose. Provides a capacitance level rated at 3900 pF to maintain circuit stability. Constructed with dielectric material specified as Polyphenylene Sulfide (PPS), Metallized - Stacked. Maximum installed height of 0.039" (1.00mm) for components affixed to the board. Mounting configuration Surface Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR)Cut Tape (CT)Digi-Reel® for safeguarding or transporting components. Style of the enclosure/case 1206 (3216 Metric) that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component ECH-U(B). Details on package size 0.126" L x 0.063" W (3.20mm x 1.60mm) for electrical or mechanical components. Measurement dimensions 0.126" L x 0.063" W (3.20mm x 1.60mm) for component specifications. Termination method Solder Pads for electrical or mechanical connections. Precision tolerance level ±5% in manufacturing processes. The highest AC voltage specification 30V for the device. The highest DC voltage specification 50V for components.
