Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | C274 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Storage Capacity Electrical | 7.5 µF | |
| Accuracy Tolerance Percentage | ±5% | |
| AC Voltage Max | 470V | |
| DC Voltage Max | - | |
| Insulating Dielectric Type | Polypropylene (PP), Metallized | |
| Series Resistance Equivalent | - | |
| Ambient Temp Range | -25°C ~ 85°C | |
| Attachment Mounting Style | Chassis, Stud Mount | |
| Component Housing Style | Radial, Can | |
| Package Size Specs | 1.378" Dia (35.00mm) | |
| Maximum Mounted Height | 2.303" (58.50mm) | |
| Circuit End Method | Quick Connect - 0.250" (6.3mm) | |
| Pin Lead Gap | 0.394" (10.00mm) | |
| Intended Uses | Motor Run | |
| Performance Rating Specs | - | |
| Key Product Highlights | - |
Description
Perfectly designed for situations involving Motor Run. Provides a capacitance level rated at 7.5 µF to maintain circuit stability. Constructed with dielectric material specified as Polypropylene (PP), Metallized. Maximum installed height of 2.303" (58.50mm) for components affixed to the board. Lead spacing 0.394" (10.00mm) to meet PCB design requirements. Mounting configuration Chassis, Stud Mount for structural stability. Temperature range -25°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Radial, Can that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component C274. Details on package size 1.378" Dia (35.00mm) for electrical or mechanical components. Measurement dimensions 1.378" Dia (35.00mm) for component specifications. Termination method Quick Connect - 0.250" (6.3mm) for electrical or mechanical connections. Precision tolerance level ±5% in manufacturing processes. The highest AC voltage specification 470V for the device.
