Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | B3277* - MKP DC-Link | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Storage Capacity Electrical | 210 µF | |
| Accuracy Tolerance Percentage | ±10% | |
| AC Voltage Max | - | |
| DC Voltage Max | 900V | |
| Insulating Dielectric Type | Polypropylene (PP), Metallized | |
| Series Resistance Equivalent | 1.3 mOhms | |
| Ambient Temp Range | -40°C ~ 105°C | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 12-DIP | |
| Package Size Specs | 2.264" L x 5.118" W (57.50mm x 130.00mm) | |
| Maximum Mounted Height | 2.283" (58.00mm) | |
| Circuit End Method | PC Pins | |
| Pin Lead Gap | 2.067" (52.50mm) | |
| Intended Uses | DC Link, DC Filtering | |
| Performance Rating Specs | - | |
| Key Product Highlights | Long Life |
Description
Perfectly designed for situations involving DC Link, DC Filtering. Provides a capacitance level rated at 210 µF to maintain circuit stability. Constructed with dielectric material specified as Polypropylene (PP), Metallized. Displays ESR rated at 1.3 mOhms. Equipped with features categorized as Long Life. Maximum installed height of 2.283" (58.00mm) for components affixed to the board. Lead spacing 2.067" (52.50mm) to meet PCB design requirements. Mounting configuration Through Hole for structural stability. Temperature range -40°C ~ 105°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case 12-DIP that offers mechanical and thermal protection. Product status Active concerning availability and lifecycle. Classification series for the product or component B3277* - MKP DC-Link. Details on package size 2.264" L x 5.118" W (57.50mm x 130.00mm) for electrical or mechanical components. Measurement dimensions 2.264" L x 5.118" W (57.50mm x 130.00mm) for component specifications. Termination method PC Pins for electrical or mechanical connections. Precision tolerance level ±10% in manufacturing processes. The highest DC voltage specification 900V for components.
