Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | B3252* - MKT General Purpose | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 0.022 µF | |
| Accuracy Tolerance Percentage | ±5% | |
| AC Voltage Max | 200V | |
| DC Voltage Max | 400V | |
| Insulating Dielectric Type | Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked | |
| Series Resistance Equivalent | - | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Radial | |
| Package Size Specs | 0.287" L x 0.177" W (7.30mm x 4.50mm) | |
| Maximum Mounted Height | 0.374" (9.50mm) | |
| Circuit End Method | PC Pins | |
| Pin Lead Gap | 0.197" (5.00mm) | |
| Intended Uses | Automotive; EMI, RFI Suppression | |
| Performance Rating Specs | - | |
| Key Product Highlights | - |
Description
Perfectly designed for situations involving Automotive; EMI, RFI Suppression. Provides a capacitance level rated at 0.022 µF to maintain circuit stability. Constructed with dielectric material specified as Polyester, Polyethylene Terephthalate (PET), Metallized - Stacked. Maximum installed height of 0.374" (9.50mm) for components affixed to the board. Lead spacing 0.197" (5.00mm) to meet PCB design requirements. Mounting configuration Through Hole for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Radial that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component B3252* - MKT General Purpose. Details on package size 0.287" L x 0.177" W (7.30mm x 4.50mm) for electrical or mechanical components. Measurement dimensions 0.287" L x 0.177" W (7.30mm x 4.50mm) for component specifications. Termination method PC Pins for electrical or mechanical connections. Precision tolerance level ±5% in manufacturing processes. The highest AC voltage specification 200V for the device. The highest DC voltage specification 400V for components.
