Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | PhaseCap® Premium | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 90 µF | |
| Accuracy Tolerance Percentage | -5%, +10% | |
| AC Voltage Max | 570V | |
| DC Voltage Max | - | |
| Insulating Dielectric Type | Polypropylene (PP) | |
| Series Resistance Equivalent | - | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Attachment Mounting Style | Chassis, Stud Mount | |
| Component Housing Style | Radial, Can | |
| Package Size Specs | 5.354" Dia (136.00mm) | |
| Maximum Mounted Height | 7.874" (200.00mm) | |
| Circuit End Method | Terminal Block | |
| Pin Lead Gap | 0.827" (21.00mm) | |
| Intended Uses | 3 Phase, Power Factor Correction (PFC) | |
| Performance Rating Specs | - | |
| Key Product Highlights | - |
Description
Perfectly designed for situations involving 3 Phase, Power Factor Correction (PFC). Provides a capacitance level rated at 90 µF to maintain circuit stability. Constructed with dielectric material specified as Polypropylene (PP). Maximum installed height of 7.874" (200.00mm) for components affixed to the board. Lead spacing 0.827" (21.00mm) to meet PCB design requirements. Mounting configuration Chassis, Stud Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Radial, Can that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Classification series for the product or component PhaseCap® Premium. Details on package size 5.354" Dia (136.00mm) for electrical or mechanical components. Measurement dimensions 5.354" Dia (136.00mm) for component specifications. Termination method Terminal Block for electrical or mechanical connections. Precision tolerance level -5%, +10% in manufacturing processes. The highest AC voltage specification 570V for the device.
