Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | ModCap™ - High Frequency | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Storage Capacity Electrical | 880 µF | |
| Accuracy Tolerance Percentage | ±10% | |
| AC Voltage Max | - | |
| DC Voltage Max | 1350V (1.35kV) | |
| Insulating Dielectric Type | Polypropylene (PP) | |
| Series Resistance Equivalent | - | |
| Ambient Temp Range | -40°C ~ 75°C | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | Module | |
| Package Size Specs | 8.071" L x 3.543" W (205.00mm x 90.00mm) | |
| Maximum Mounted Height | 6.713" (170.50mm) | |
| Circuit End Method | Connector | |
| Pin Lead Gap | - | |
| Intended Uses | DC Link, DC Filtering | |
| Performance Rating Specs | - | |
| Key Product Highlights | - |
Description
