Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 085 CS | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 10 µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 6.3 V | |
| Series Resistance Equivalent | 48Ohm | |
| Expected Life at Temperature | 1500 Hrs @ 85°C | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Optical Polarization Mode | - | |
| Performance Rating Specs | - | |
| Intended Uses | General Purpose | |
| Low-Freq Ripple Amps | - | |
| High-Freq Ripple Amps | 16.5 mA @ 10 kHz | |
| AC Resistance Value | 20 Ohms | |
| Pin Lead Gap | - | |
| Package Size Specs | 0.346" L x 0.146" W (8.80mm x 3.70mm) | |
| Maximum Mounted Height | 0.154" (3.90mm) | |
| SMD Pad Footprint | 0.346" L x 0.146" W (8.80mm x 3.70mm) | |
| Attachment Mounting Style | Surface Mount | |
| Component Housing Style | Nonstandard SMD |
Description
Perfectly designed for situations involving General Purpose. Provides a capacitance level rated at 10 µF to maintain circuit stability. Displays ESR rated at 48Ohm. Maximum installed height of 0.154" (3.90mm) for components affixed to the board. Configured with 20 Ohms impedance to maintain signal quality. Operates with a durability of 1500 Hrs @ 85°C at specified temperature. Mounting configuration Surface Mount for structural stability. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Style of the enclosure/case Nonstandard SMD that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. High-frequency ripple current 16.5 mA @ 10 kHz for improved performance. Classification series for the product or component 085 CS. Details on package size 0.346" L x 0.146" W (8.80mm x 3.70mm) for electrical or mechanical components. Measurement dimensions 0.346" L x 0.146" W (8.80mm x 3.70mm) for component specifications. Dimensions of surface mount pads 0.346" L x 0.146" W (8.80mm x 3.70mm) for PCB design. Precision tolerance level ±20% in manufacturing processes. The operating voltage rating of the device 6.3 V.
