Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | B41789 | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 1000 µF | |
| Accuracy Tolerance Percentage | -10%, +30% | |
| Rated Operating Voltage | 63 V | |
| Series Resistance Equivalent | 61mOhm @ 100Hz | |
| Expected Life at Temperature | 10000 Hrs @ 125°C | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Optical Polarization Mode | Polar | |
| Performance Rating Specs | - | |
| Intended Uses | Automotive | |
| Low-Freq Ripple Amps | - | |
| High-Freq Ripple Amps | 7.5 A @ 10 kHz | |
| AC Resistance Value | 18 mOhms | |
| Pin Lead Gap | 0.846" (21.50mm) | |
| Package Size Specs | 0.827" Dia (21.00mm) | |
| Maximum Mounted Height | 1.535" (39.00mm) | |
| SMD Pad Footprint | - | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | Radial, Can - Snap-In - 3 Lead |
Description
Perfectly designed for situations involving Automotive. Provides a capacitance level rated at 1000 µF to maintain circuit stability. Displays ESR rated at 61mOhm @ 100Hz. Maximum installed height of 1.535" (39.00mm) for components affixed to the board. Configured with 18 mOhms impedance to maintain signal quality. Lead spacing 0.846" (21.50mm) to meet PCB design requirements. Operates with a durability of 10000 Hrs @ 125°C at specified temperature. Mounting configuration Through Hole for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case Radial, Can - Snap-In - 3 Lead that offers mechanical and thermal protection. The Polar type of polarization for optical or RF applications. Product status Obsolete concerning availability and lifecycle. High-frequency ripple current 7.5 A @ 10 kHz for improved performance. Classification series for the product or component B41789. Details on package size 0.827" Dia (21.00mm) for electrical or mechanical components. Measurement dimensions 0.827" Dia (21.00mm) for component specifications. Precision tolerance level -10%, +30% in manufacturing processes. The operating voltage rating of the device 63 V.
