Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | MLS | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Storage Capacity Electrical | 17000 µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 7.5 V | |
| Series Resistance Equivalent | 77mOhm @ 120Hz | |
| Expected Life at Temperature | 10000 Hrs @ 85°C | |
| Ambient Temp Range | -55°C ~ 125°C | |
| Optical Polarization Mode | Polar | |
| Performance Rating Specs | - | |
| Intended Uses | General Purpose | |
| Low-Freq Ripple Amps | 12.5 A @ 120 Hz | |
| High-Freq Ripple Amps | 13.5 A @ 20 kHz | |
| AC Resistance Value | - | |
| Pin Lead Gap | 1.000" (25.40mm) | |
| Package Size Specs | 1.500" L x 1.750" W (38.10mm x 44.45mm) | |
| Maximum Mounted Height | 0.500" (12.70mm) | |
| SMD Pad Footprint | - | |
| Attachment Mounting Style | Chassis Mount | |
| Component Housing Style | FlatPack, Tabbed |
Description
Perfectly designed for situations involving General Purpose. Provides a capacitance level rated at 17000 µF to maintain circuit stability. Facilitates a maximum output current level set as 12.5 A @ 120 Hz. Displays ESR rated at 77mOhm @ 120Hz. Maximum installed height of 0.500" (12.70mm) for components affixed to the board. Lead spacing 1.000" (25.40mm) to meet PCB design requirements. Operates with a durability of 10000 Hrs @ 85°C at specified temperature. Mounting configuration Chassis Mount for structural stability. Temperature range -55°C ~ 125°C for environmental conditions impacting thermal efficiency. Type of housing Bulk for safeguarding or transporting components. Style of the enclosure/case FlatPack, Tabbed that offers mechanical and thermal protection. The Polar type of polarization for optical or RF applications. Product status Active concerning availability and lifecycle. High-frequency ripple current 13.5 A @ 20 kHz for improved performance. Low-frequency ripple current 12.5 A @ 120 Hz for improved performance. Classification series for the product or component MLS. Details on package size 1.500" L x 1.750" W (38.10mm x 44.45mm) for electrical or mechanical components. Measurement dimensions 1.500" L x 1.750" W (38.10mm x 44.45mm) for component specifications. Precision tolerance level ±20% in manufacturing processes. The operating voltage rating of the device 7.5 V.
