Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | CeraLink™ SP | |
| IC Encapsulation Type | Tube | |
| Availability Status | Obsolete | |
| Storage Capacity Electrical | 20µF | |
| Accuracy Tolerance Percentage | ±20% | |
| Rated Operating Voltage | 500 V | |
| Insulating Dielectric Type | Ceramic | |
| Capacitor Component Count | 2 | |
| Circuit Configuration Style | Isolated | |
| Temp Drift Factor | - | |
| Performance Rating Specs | AEC-Q200 | |
| Attachment Mounting Style | Through Hole | |
| Component Housing Style | 6-DIP | |
| Vendor Package Type | - | |
| Package Size Specs | 1.299" L x 0.866" W (33.00mm x 22.00mm) | |
| Maximum Mounted Height | 0.472" (12.00mm) |
Description
Provides a capacitance level rated at 20µF to maintain circuit stability. Employs a circuit variation identified as Isolated. Constructed with dielectric material specified as Ceramic. Maximum installed height of 0.472" (12.00mm) for components affixed to the board. Mounting configuration Through Hole for structural stability. Overall capacitors 2 used in circuit design. Type of housing Tube for safeguarding or transporting components. Style of the enclosure/case 6-DIP that offers mechanical and thermal protection. Product status Obsolete concerning availability and lifecycle. Criteria AEC-Q200 for electrical, mechanical, or environmental performance. Classification series for the product or component CeraLink™ SP. Details on package size 1.299" L x 0.866" W (33.00mm x 22.00mm) for electrical or mechanical components. Measurement dimensions 1.299" L x 0.866" W (33.00mm x 22.00mm) for component specifications. Precision tolerance level ±20% in manufacturing processes. The operating voltage rating of the device 500 V.
