Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | - | |
| IC Encapsulation Type | Bulk | |
| Availability Status | Active | |
| Pin Interface Category | Sleeve & Plunger (Pogo Pins) | |
| Attachment Mounting Style | Surface Mount | |
| Top Operational Elevation | 0.379" (9.63mm) | |
| Optimal Use Elevation | 0.320" (8.13mm) | |
| Lowest Operational Elevation | 0.261" (6.63mm) | |
| Solder Pad Size | Circular - 0.072" (1.83mm) | |
| Starting Actuation Force | 85gf | |
| Mid-Stroke Force | - | |
| Actuator Plunger Dimension | 0.042" (1.07mm) Dia | |
| Key Product Highlights | - | |
| Connection Durability Cycles | 1000000 | |
| Pin Alloy Composition | Brass | |
| Pin Surface Treatment | Gold | |
| Pin Coating Depth | 20.0µin (0.51µm) | |
| Ampere Capacity Rating | 2A |
Description
Includes contact finish plated at Gold to improve conductivity. Represents the thickness of the contact finish recorded at 20.0µin (0.51µm). Constructed from the contact material known as Brass. Makes use of a contact type known as Sleeve & Plunger (Pogo Pins). Facilitates a maximum output current level set as 0.261" (6.63mm). Sets the ampere rating to 2A. Supports 1000000 mating cycles to ensure enduring reliability. Maximum operational height 0.379" (9.63mm) for safe performance. Minimum working altitude 0.261" (6.63mm) for safety and comfort. Mounting configuration Surface Mount for structural stability. Initial force 85gf required for accurate actuation. Type of housing Bulk for safeguarding or transporting components. Dimensions of the pad Circular - 0.072" (1.83mm) for PCB design. The 0.042" (1.07mm) Dia size of the plunger for mechanical functionality. Product status Active concerning availability and lifecycle. Recommended height 0.320" (8.13mm) for ergonomic or operational standards.
