Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Faston | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT) | |
| Availability Status | Active | |
| End Terminal Category | Angled - 90°, Flag | |
| Connector Polarity Type | Female | |
| Blade Terminal Width | 0.250" (6.35mm) | |
| Terminal Tab Gauge | 0.032" (0.81mm) | |
| Fast-On Tab Extension | 0.305" (7.75mm) | |
| Full Overall Length | - | |
| Circuit End Method | Crimp | |
| AWG Wire Size | 10-12 AWG | |
| Protective Insulation Layer | Non-Insulated | |
| Attachment Mounting Style | Free Hanging (In-Line), Right Angle | |
| Key Product Highlights | - | |
| Visual Hue | - | |
| Pin Alloy Composition | Phosphor Bronze | |
| Pin Surface Treatment | Silver |
Description
Includes contact finish plated at Silver to improve conductivity. Constructed from the contact material known as Phosphor Bronze. Defined with Female gender configuration for connector compatibility. Insulation with a rating of Non-Insulated for safety and efficiency. Mounting configuration Free Hanging (In-Line), Right Angle for structural stability. Type of housing Tape & Reel (TR)Cut Tape (CT) for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component Faston. The size of the tab 0.305" (7.75mm) for connectors or mechanical assemblies. The width of the tab 0.032" (0.81mm) for mechanical or electrical connections. The breadth of the tab 0.250" (6.35mm) for connectors or mechanical assemblies. Classification of terminal Angled - 90°, Flag for electrical or mechanical connections. Termination method Crimp for electrical or mechanical connections. Size of wire gauge 10-12 AWG according to electrical standards.
