Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | Disco™ ReelSmart™ | |
| IC Encapsulation Type | Tape & Reel (TR)Cut Tape (CT) | |
| Availability Status | Active | |
| End Terminal Category | Standard | |
| Connector Polarity Type | Female | |
| Blade Terminal Width | 0.187" (4.75mm), 0.205" (5.21mm) | |
| Terminal Tab Gauge | 0.032" (0.81mm) | |
| Fast-On Tab Extension | - | |
| Full Overall Length | 0.780" (19.81mm) | |
| Circuit End Method | Crimp | |
| AWG Wire Size | 14-16 AWG | |
| Protective Insulation Layer | Fully Insulated | |
| Attachment Mounting Style | Free Hanging (In-Line) | |
| Key Product Highlights | Butted Seam | |
| Visual Hue | Blue | |
| Pin Alloy Composition | Brass | |
| Pin Surface Treatment | Tin |
Description
Offered in a shade referred to as Blue to enhance the system's aesthetics. Includes contact finish plated at Tin to improve conductivity. Constructed from the contact material known as Brass. Equipped with features categorized as Butted Seam. Defined with Female gender configuration for connector compatibility. Insulation with a rating of Fully Insulated for safety and efficiency. The complete length 0.780" (19.81mm) for thorough dimensional reference. Mounting configuration Free Hanging (In-Line) for structural stability. Type of housing Tape & Reel (TR)Cut Tape (CT) for safeguarding or transporting components. Product status Active concerning availability and lifecycle. Classification series for the product or component Disco™ ReelSmart™. The width of the tab 0.032" (0.81mm) for mechanical or electrical connections. The breadth of the tab 0.187" (4.75mm), 0.205" (5.21mm) for connectors or mechanical assemblies. Classification of terminal Standard for electrical or mechanical connections. Termination method Crimp for electrical or mechanical connections. Size of wire gauge 14-16 AWG according to electrical standards.
