Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | AMPMODU 50/50 Grid | |
| IC Encapsulation Type | Tube | |
| Availability Status | Active | |
| Interface Connector Category | Header | |
| Pin Interface Category | Male Pin | |
| Mating Connector Pitch | 0.050" (1.27mm) | |
| Switch Position Options | 50 | |
| Grid Row Count | 2 | |
| Mating Row Interval | 0.050" (1.27mm) | |
| Populated Position Count | All | |
| Design Style Variant | Board to Board | |
| Connector Shroud Coverage | Shrouded - 4 Wall | |
| Attachment Mounting Style | Surface Mount | |
| Circuit End Method | Solder | |
| Secure Attachment Method | Push-Pull | |
| Engagement Pin Length | 0.120" (3.05mm) | |
| Tail Pin Extension | - | |
| Full Pin Contact Span | - | |
| Barrier Wall Height | 0.367" (9.33mm) | |
| Pin Profile Design | Circular | |
| Engaging Pin Coating | Gold | |
| Engagement Layer Thickness | 30.0µin (0.76µm) | |
| Post-Contact Pin Layer | Tin | |
| Pin Alloy Composition | Phosphor Bronze | |
| Dielectric Insulation Type | Liquid Crystal Polymer (LCP) | |
| Key Product Highlights | Board Lock | |
| Ambient Temp Range | -65°C ~ 105°C | |
| Dust Water Resistance Rating | - | |
| Fire Resistance Classification | UL94 V-0 | |
| Covering Wire Hue | Black | |
| Ampere Capacity Rating | 0.5A per Contact | |
| Max Voltage Specification | - |
Description
Specifies connector spacing defined as 0.050" (1.27mm) for suitable PCB layout. Features a connector type acknowledged as Header. Offers mating contact finish rated at Gold. Provides a post-contact finish defined by Tin. Emphasizes the thickness of the mating finish denoted as 30.0µin (0.76µm). Specifies the length of the mating contact noted at 0.120" (3.05mm). Constructed from the contact material known as Phosphor Bronze. Crafted with a contact shape described as Circular. Makes use of a contact type known as Male Pin. Sets the ampere rating to 0.5A per Contact. Utilizes a fastening type recognized as Push-Pull. Equipped with features categorized as Board Lock. Available in Black color of insulation for easy identification. An insulation height of 0.367" (9.33mm) provides sufficient electrical clearance. Constructed with Liquid Crystal Polymer (LCP) insulation material for durability. Classification UL94 V-0 for adherence to fire safety regulations. Mounting configuration Surface Mount for structural stability. Overall number of positions 50 for switches or mechanical components. Occupied positions All for mechanical assembly. Overall rows 2 for setting up matrices or displays. Temperature range -65°C ~ 105°C for environmental conditions impacting thermal efficiency. Type of housing Tube for safeguarding or transporting components. The distance 0.050" (1.27mm) to achieve correct alignment with the corresponding connector. Product status Active concerning availability and lifecycle. The 0.050" (1.27mm) spacing between rows for proper connector alignment to ensure a precise fit. Classification series for the product or component AMPMODU 50/50 Grid. Extent of insulation Shrouded - 4 Wall for protective measures. Style variant Board to Board for design or arrangement. Termination method Solder for electrical or mechanical connections.
