Product Attributes
| Type | Description | |
|---|---|---|
| Category | ||
| Import Duty Classification | - | |
| Product Series Line | 6277, Kyocera | |
| IC Encapsulation Type | Tape & Reel (TR) | |
| Flat Flexible Cable Style | FPC | |
| Attachment Mounting Style | Surface Mount, Right Angle | |
| Pin Interface Style | Contacts, Top and Bottom | |
| Switch Position Options | 6 | |
| Component Spacing Distance | 0.020" (0.50mm) | |
| Circuit End Method | Solder | |
| Flat Flexible Cable Depth | 0.20mm | |
| PCB Clearance Height | 0.035" (0.88mm) | |
| Retention Lock Mechanism | Flip Lock, Backlock | |
| Wire Termination Style | Notched | |
| Pin Alloy Composition | Copper Alloy | |
| Pin Surface Treatment | Gold | |
| Casing Build Material | Thermoplastic | |
| Activator Construction Material | - | |
| Key Product Highlights | Zero Insertion Force (ZIF) | |
| Max Voltage Specification | 50V | |
| Ambient Temp Range | -40°C ~ 85°C | |
| Fire Resistance Classification | - |
Description
Designed with a cable end configuration known as Notched. Showcases connector/contact type specified as Contacts, Top and Bottom. Includes contact finish plated at Gold to improve conductivity. Constructed from the contact material known as Copper Alloy. Shows FFC/FCB thickness noted at 0.20mm. Equipped with features categorized as Zero Insertion Force (ZIF). Employs a flat flexible configuration known as FPC. Maintains a height of 0.035" (0.88mm) above the board to accommodate assembly and clearance requirements. Constructed from Thermoplastic material to guarantee strength and reliability. Mechanism Flip Lock, Backlock for locking to enhance safety. Mounting configuration Surface Mount, Right Angle for structural stability. Overall number of positions 6 for switches or mechanical components. Temperature range -40°C ~ 85°C for environmental conditions impacting thermal efficiency. Type of housing Tape & Reel (TR) for safeguarding or transporting components. Distance 0.020" (0.50mm) for arranging components or aligning connectors. Classification series for the product or component 6277, Kyocera. Termination method Solder for electrical or mechanical connections. Voltage specification 50V for electronic devices.
